1450VA Solar Home Inverter, with In-built Lithium Battery, Portable, Model: PL-1450W
- Battery : Lithium Iron Phosphate LiFePo4
- Rated Power Output : 1000VA
- Voltage & Type : AC - 230 V,50Hz, Pure Sine Wave
- DC - Output : 12V- Cigarette Lighter Socket
- Other DC Outputs : 5V to 20 V & DC Ports
Charging Input Power (4 Way of Recharge) :
- AC Inbuilt Charger
- Solar Panel PV Charge
- Car Charge Input (From Cigarette Socket)
- Portable Petrol Engine Charger
Application
Drone Battery Charging Smartphone Tablet, Laptop Car Air Compressor, Lalten, Mini Fridge, Car Fridge, Led Light, Flood Light, Wifi - Router, Vacuum Cleaner, Projector, Coffee Maker, Blender, Cordless Drill, Tav Mug, Rice Cooker, Stand Fan, Cpap,GoPro Camera, Camera, Electric Pan, Speaker, Electric Blanket, Desktop,Tv, Soldering Iron, Water Pump, Hair Straightener, Electric Kettle, Electric Multi Cooker, Cutter, Bldc Fan, Grinder, Hair Dryer, Egg Boiler, Lithium Battery Charger, Electric Lunch Box, Roster
Description
- This is a Portable multifunctional Lithium Battery based UPS / Inverter.
- This inverter gives AC 230V output & also 4* DC-5V for smartphone charging & 5* 12V DC output for running 12V DC appliances. This 1450W Inverter Model has an inbuilt 15W High Power has two mode LED Light.
- The main advantage of this solar inverter is that it is a UPS, Hence it can supply Main AC 230V to home appliances & when main power fails, the home load automatically shifts over to Battery Inverter Power.
- This is a lightweight Portable Power Inverter & can be used at Household & as well can be carried away anywhere for outdoor/ field power applications. / Outdoor Camping activities
- This inverter has a big Lithium Power Pack of 12.8V-100 AH, which is largest in its Class & hence have a longer backup period
The Lithium Battery of this Solar Invertor can be charged by any of the 4 ways :
- 1) AC 230 V mains (Grid Power) Inbuilt 20A-250Watt fast charger
- 2) Car charging through C.G Port in running car 150W.(C.G Load provided)
- 3) Charging with Solar Panel 200W (Optional)
- 4) Battery can be expended with 12.8V-100AH extra battery (Optional) & Further both batteries can be fast charged (in 1Hr by Portable Engine Charger , when all charging options are exhausted).
Apart From above, the Battery Back up Period can be further extended by connecting additional Battery bank of 100Ah at its Expansion Socket.
The Remaining Battery Power can be judged trough its LCD Display.
This product has similar application and use like other Brand Like Excide, Apro, Su-KAm, Luminous,Lento, Microtech Etc.
This Premium product is Outcome of excellent Hard work of HPM's R&D Engineers. Himalayan Power is more than 25-year company offers Complete Power & Lighting Solutions through > 300 Products & Models. HPM is a 100% Make in India Company with after Sales & Services & spare parts at very economical prices.
Product Information
- Battery: Lithium Iron Phosphate LiFePo4
- Cell Type : Prismatic 3.2 V- 100 AH
- Battery Voltage : 12.8 V (4S)
- Peak Capacity : 12.8V - 100 AH (1280 Wh)
- Life Cycles : ≥ 2000 Cycles to 80% Capacity (80 % DOD @ 25°C, Discharge Rate 1 C)
- BMS (Battery Management System) : Multiple Safety Protections: Over Load, Over Voltage, Over Current, Over Temperature, Short Circuit, and Cell Balancing
- Battery Expansion : Yes, Expandable, can Add 1 Pack 12.8V - 100 AH
- Shelf Life : Charge Every 3 - 6 Months
AC 230 Volt Output (Invertor Power Supply)
- Continues Rated Power Output : 1000 VA
- Peak Output Power : 1100 VA
- Voltage & Type : AC - 230 V,50Hz, Pure Sine Wave
- THD : < 2% (Full R Load)
- Power Factor : 0.8
- Over Load : 110% < Load <120% @ 1 min 120% < Load <150% @ 0.5 S
- Power Less (No Load & Turned- Off) : < 10W
- AC Output Back time @ 70% of rated load (VA) : ≥ 3.5 Hours
- Max. Effecient (>70% Load) : < 85%
- Output Socket : Indian Version AC Socket x 1(US/UK/EU/AU Socket)
DC - Output- 12V- Cigarette Lighter Socket
- Output Voltage : 12.8 ± 1 V
- Continous Output Current : 13 A (Max. 150 Watt)
- DC Output Over Load Current Protection : Yes >13 A (Through Fuse Provided in C.G Pin)
- DC Output ShortCircuit Protection : Yes (through BMS)
Other DC Outputs - 5V to 20 V & DC Ports
- USB Output (1 to 2) : 2* 5V DC, 2.4 A (12W Per Port)
- USB Output Fast Charging QC 3.0 (3) : 1* 5V - 12V DC (18W-Max) 5V3A, 9V 2A, 12V 1.5A
- Type - C USB (4): 1* 'C' Type - 1* USB C PD 3.0 (60W) 5V 5A, 9V 3A, 12V 1.5A, 15 V 1.5A, 20 V 1.5A
- 12V DC -DC 5521 (2 Ports): 4 x 12V, 5A-60 W Each (5.5mm x 2.1 mm)
- 12V DC -DC 5521 Short Ckt & Overload Protection : Through 5Amp Glass Fuse
- USB & DC Over Load Current Protection : Yes
- USB & DC Output short Circuit Protection : Yes (Disconnect Load Recovery)
- Illumination / LED Flash Lighting : 15W (2 Modes: Low OR Bright).
Indicators in Panel
- Battery Level / Status Indicators : LCD Display
- Function Indicators : Fault / AC Output / Mains charging /Modes/ Load Percentage, Battery Voltage, Mains Voltage, Temperature, UPS / Inverter Mode
Charging Input Power (4 Way of Recharge)
- AC Inbuilt Charger (Charging From Grid Power) (AC input 120V to 275V) : Inbuilt Charging 20 Amps 6-7 Hours
- Solar Panel PV Charge : 2 Parallel (18V/ 8.3 Amps 150W) Max 300 W Charging Time 7 - 8 Hours
- Car Charge Input (From Cigarette Socket) : 14V, 10 Amps Max. Charging Time 10- 11 Hours
- Portable Petrol Engine Charger (Applicable only when Inverter is connected with extra Battery Bank) :15 V - 60 Amps (750 Watts Maximum ) Charging time Approx 3 Hr for 80% Charging.
Heat Dissipation: Air Cooling (Fan), Aluminium Housing
IP Rate : IP 32 Protected from Water Spary < 15˚From Vertical
Working Condition
- Charge Temperature : 0˚C ~ 45˚C
- Operating Usage Temp. : -10˚C ~ 45˚C
- Operation Storage Humidity : 5% ~ 90%
Product Size & Weight
- Dimensions (LxWxH) : 290*300*320mm
- Net Weight : 19.8kg
Package Contents :
- 1* 1450 Watt Portable Lithium Power Inverter PL-1450W
- 1* 3 pin Mains AC Cord
- 1* User Manual
- Solar Panel 2 Parallel (18V/ 8.3 Amps 150W) Max 300 W (Optional)
- 1* Car Charger (CG-CG Cable) optional
